Super Flower Leadex III GOLD-1000W ATX3.1, PCIe5.1

Avail the all-new Super Flower Leadex III GOLD-1000W SMPS from Kharidiye.com at the best price. Best in-class features includes:

Specification Details
Model No. LEADEX III GOLD UP ATX 3.1 1000W (SF-1000F14G)
Wattage 1000 W
Efficiency 80 PLUS Gold: 87 % @ 20 %, 90 % @ 50 %, 87 % @ 100 % (115 V)
Fan 140 mm Fluid-Dynamic Bearing (FDB), 9-blade design, copper shaft

About the item:

  • ATX 3.1 Compatibility with 200% Power Excursion Support
    Compliant with Intel’s ATX 3.1 standard, this PSU is capable of handling up to 200% power excursions, providing stable performance even during intense, sudden power demands. It includes HCS terminals and dual 8-pin sockets leading to a 12+4-pin GPU plug, preventing excessive cable bending for a safer, more reliable connection.

  • High-Efficiency 80 PLUS Gold Certification
    Certified as 80 PLUS Gold, it achieves efficiencies of approximately 87 % at 20 %, 90 % at 50 %, and 87 % at full load (115 V source), ensuring strong energy savings and reduced heat generation.

  • Advanced Thermal & Fan Design
    Equipped with a 140 mm Fluid-Dynamic-Bearing (FDB) fan featuring a distinctive 9-blade design and copper shaft, the PSU offers high airflow, accurate fan RPM control, quieter operation, and enhanced durability. It also supports an ECO (semi-fanless) mode to reduce noise when idle.

  • Fully Modular with Modern Cable Design
    The fully modular design uses flexible ribbon-style cables, enhancing cable management and airflow. Additionally, it includes a revised, safer 12V-2×6 (12VHPWR) connector for compatibility with next-generation PCIe 5 graphics cards delivering up to 600 W.

  • Robust Componentry & Protection Suite
    Built with top-tier Japanese capacitors for improved reliability and longevity, this PSU features a full array of protection mechanisms—including over-voltage, over-current, over-power, short-circuit, under-voltage, over-temperature, no-load, and surge/inrush protection—to safeguard both the unit and your system.

Description

About Super Flower Leadex III GOLD-1000W SMPS

Specification Category Details
Model & Certification Model: LEADEX III GOLD UP ATX 3.1 1000W (SF-1000F14G); 80 PLUS Gold certified; also ranges “Cybernetics Certified Efficiency: Gold”
Input & Standards AC Input: 100–240 V, 50/60 Hz, Active PFC; Compliant with Intel EPS 2.92 & ATX 3.1 specifications
Cooling System 140 mm FDB fan with unique 9-blade design; features copper shaft offering stability, better heat dissipation, and quieter operation
Protection Features OVP, OCP, OPP, SCP, UVP, OTP, NLO, SIP (comprehensive safety protection suite)
Certifications Compliance with global safety standards: cTÜVus, TÜV, CB, CE, FCC, UKCA, RCM, BSMI, RoHS, KCC, EAC, CCC
Dimensions & Thermal Dimensions: 150 mm × 150 mm × 86 mm (L × W × H); passed 50 °C hot testing
Cable Configuration Fully modular design with ribbon cables:
– 20+4 pin ATX (600 mm)
– 2 × (4+4) pin CPU (700 mm)
– 4 × PCIe 6+2 pin (700 mm)
– 1 × PCIe 12V-2×6 cable (700 mm)
– SATA and Molex connectors with respective lengths
Power Outputs +12 V rail: ≈999.6 W
+3.3 V & +5 V combined: 120 W
-12 V: 6 W
+5 VSB: 15 W
Total: 1000 W
Additional Features Full ATX 3.1 & PCIe 5 (PCIe 5.1) ready with safe HCS terminals, dual 8-pin sockets to 12+4-pin GPU connector; ECO fan control modes (auto/ECO)
